Control pad: capacitive touch (control pad detachable)
Connect up to 4 HDMI AV sources to 2 HDMI displays
Full HDCP compatibility
HDMI (3D, Audio Return Channel and Deep Color)
Supports Dolby True HD and DTS HD Master Audio
•Audio Return Channel (ARC) function
EDID expert technology function allows various configuration settings through various EDID modes
High resolution video support: 480p, 720p, 1080p (1920 x 1080) / up to WUXGA (1920 x 1200)
HDMI input source dedicated audio output: supports both optical and coaxial digital audio and supports one stereo output
Projector RS-232 or IR control
Electric screen and elevation control (Up / Stop / Down)
Built-in digital amplifier (160W, 8Ω)
Supports 10Band Equalizer function for each audio channel
Wireless microphone 900MHz 1CH application (SIC-1320W) / Hand or Pin microphone selection
Interlocking with central integrated control program (Smart Manager) is possible (Option)
basic configuration
Product specification
model name
SIC-1320 / SIC-1320W
control touchpad
Capacitive touch control / separate external connection possible
HDMI input
4 x HDMI Type A Female
HDMI output
2 x HDMI Type A Female
video resolution
480p, 720p, 1080i, 1080p (1920x1080); Up to WUXGA (1920 x 1200)
audio input
PC, Laptop(3.5mm Stereo x 2)
audio output
Optical, Coaxial, Stereo RCA x 1
DSP EQ
10Band EQ / Graphic Equalizer (Mic 1, 2 EQ adjustable)
microphone input
XLR (each channel Bass, Middle, Treble) x 2
control port
RS-232 x 1 (LAN terminal)
Projector Control
RS-232 control or IR control
powertrain control
Electric Screen, Electric Elevation (Up / Stop / Down)
USB / LAN
LAN x 1, USB x 2 (PC)
digital amplifier
160W (80W/CH, 8Ω), Total Harmonic Prominence (THD+N): RL=8Ω 1/2W POWER ≤ 10%
wireless microphone
SIC-1320 : X
SIC-1320W: 900MHz 1CH / Hand or Pin Mic
remote control
(Option)
Network-based integrated control / remote control / monitoring of each classroom, reservation function
power used
AC220V, 60Hz, 150W(Max.)
Product size/weight
378(H) x 96(D) x 250(W)mm / 4.2Kg
