SRC-1321
Product Features
Control pad: capacitive touch (main body and set supplied)
Projector RS-232 control
Electric screen and elevation (Up / Stop / Down control)
Extended control terminal: Relay 1 channel
Lecture start/end: One-touch batch control
• Macro function
Interlocking with central integrated control program (Smart Manager) is possible (Option)
basic configuration
Product specification
model name
SRC-1321
control pad
Capsens method (capacitive touch)
channel capacity
AC 220V 5A/1.1Kw
communication control
RS-232C 1Port (Euro Block) / Projector Control
LAN port
1Port
USB port
1Port (Controller Configuration Port)
contact output
1Port (Euro Terminal / 8-channel sequential power supply control)
powertrain control
Electric screen, elevation (Up/Stop/Down) control
product size
Body : 147(W) x 130(H) x 48(D)mm
PAD : 155(W) x 89(H) x 25(D)mm
weight
1.5Kg (including control pad)
